| Brand Name: | TUWE |
| Model Number: | TW-90FBYFS |
| MOQ: | 1000kg |
| Price: | USD680-990/TON |
| Packaging Details: | 25kg/500kg-1000kg/per bag |
| Payment Terms: | T/T |
90℃ polyethylene sheathing material is based on polyethylene resin, adding plasticizers, stabilizers, ultraviolet absorption shielding agents and other additives, and is mixed, plasticized, kneaded and granulated. It is suitable for electric power applications. , instrumentation, communication, electrical equipment wire and cable sheath. 90℃ polyvinyl chloride sheath material has good mechanical and physical properties. Power cables made of this material have a service temperature of -20℃~90℃, and their performance meets the IEC standard TC18 and TC20 series of ST1, ST2, ST4 and ST5 cables. Technical requirements for PVC sheath, used for indoor and outdoor cables and similar occasions.
The particles of PVC cable sheath material are round and smooth, bright in color, good in internal and external lubrication, no discoloration, no oiling, good fluidity, good stability, and excellent basic performance. A good extrusion surface can be obtained by extruding with an ordinary PVC screw.
The recommended temperature settings for each zone of the extruder are as follows:
| Location | Zone 1 | Zone 2 | Zone 3 | Zone 4 | Machine neck | Machine head | Mould port |
| Temperature/°C | 150 | 155 | 160 | 170 | 175 | 175 | 170 |
The best extrusion temperature depends on the specific structure of the screw, such as aspect ratio, compression ratio, etc. If you have any technical problems after purchasing PVC sheath materials, please contact us and we will arrange engineers to provide solutions. TUWEI is committed to providing one-stop services for PVC processing, production, formulation and technology.
| N0. | Items | Unit | Results of Testing | Test Method | |
| 1 | Color | / |
Difference from standard color plate ≤ Δ1.0 |
||
| 2 | Granule size for square particles |
mm
|
2-5mm | ||
| 3 | Density | g/cm3 | ≤1.43(Customizable) | ||
| 4 | Tensile Strength | MPa | 20.5 | GB1040 | IEC60811-1-1 |
| 5 | Elongation at Break | % | 320 | ||
| 6 | Thermal Deformation | % | 30 | GB/T8815 | |
| 7 | Brittle Temperature | °C | -20°C tested | GB5470 | IEC60811-1-4 |
| 8 | Thermal stability time at 200℃ | min | 100 | GB/T8815 | |
| 9 | Volume resistivity at 20℃ | Ω·m | 8x1010 | GB1410 | IEC60167 |
| 10 | Dielectric Strength | MV/m | 25 | GB1408 | IEC60243 |
| 11 | Thermal aging strength | ℃xday | 100x10 | GB/T2951 | |
| 12 | Tensile strength after aging | MPa | 19.8 | ||
| 13 | Change rate of tensile strength | % | -3.4 | ||
| 14 | Elongation at break after aging | % | 200 | ||
| 15 | Change rate of elongation at break | % | -3.4 | ||
| 16 | Quality loss due to thermal aging | g/cm3 | 8 | ||
Suitable for wire and cable
The PVC plastic granules produced by TUWEI are widely used in extrusion, injection molding, blow molding and other processes. They are used in various profiles, special-shaped materials, edge banding, pipes, plates, sheets, wires, blown films, medical supplies, automotive supplies, household supplies and other industrial and household fields. The material performance is excellent, and the color and material performance can be customized according to customer requirements.
At the same time, we provide color customization and color matching services.
The products on this page are mainly suitable for the processing of wire and cable sheaths.
Usage: Mix evenly with raw materials for production.
Packaging: 25kg/bag or 1000kg/bag, polyethylene black, milky white printed bags or paper-plastic composite bags (can be customized according to customer needs)
Storage: Store in a cool and dry place, avoid exposure to sunlight and rain.
Samples: We provide non-customized products within 5kg for free, and you need to pay the shipping fee.
Transportation:support express delivery, sea freight, full container load, LCL...
Follow good industrial practices to avoid environmental pollution, fire and dust prevention.
For more information, please see MSDS of PVC Compounds.
|
|
